Antistatic coating is a coating designated to repel static electricity by lowering the surface resistance while maintaining the non-stickiness and corrosion resistance that are typical properties of fluorinated coatings.
Thanks to these characteristics, antistatic coating can help prevent explosions, fires, and accidents in industrial sites caused by static electricity. In precision industries, it can minimize contamination on the equipment and facilities during the manufacturing process to prevent product loss.
Specification | Product Name | Color | Processing Temperature | Average Particle Diameter | Recommended Coating | Surface Resistance |
---|---|---|---|---|---|---|
ETFE | SP-7239 | Black | 270~290℃ | 60~80㎛ | 300±100㎛ | 10⁶~10⁸Ω |
PFA | SP-5138 | Gray | 380~400℃ | 20~25㎛ | 50~100㎛ | 10⁵~10⁷Ω |
SP-539TR | Black | 380~400℃ | 20~25㎛ | 30~50㎛ | 10⁵~10⁷Ω | |
SP-539SS | Black | 380~400℃ | 20~25㎛ | 30~50㎛ | 10⁷~10⁹Ω | |
SP-5239 | Black | 360~380℃ | 30~35㎛ | 250±50㎛ | 10⁶~10⁸Ω |
Product Name | Processing Conditions | Color | Surface Resistance | |
---|---|---|---|---|
Metal Material | Insulation Material | |||
SS-4209BK-NT(EC) | 230℃ 30 minutes | Black | 10⁴~10⁵Ω | 10⁴~10⁵Ω |
SS-4209BK-MS(EC) | Black | 10⁴~10⁵Ω | 10⁷~10⁸Ω | |
SS-4209BK-FT (EC) | Black | 10⁷~10⁹Ω | 10¹⁰~10¹³Ω |
